Product
Box Speaker
The speaker consists of two 44mm tweeter drive unit and one 12-inch bass unit. It is in good treble performance, high SPL. Small size, light weight, easy hanging. It’s designed to facilitate adjustment of the angular position of hanging system and brings great convenience f
The speaker consists of two 44mm tweeter drive unit and one 12-inch bass unit. It is in good treble performance, high SPL. Small size, light weight, easy hanging.
It’s designed to facilitate adjustment of the angular position of hanging system and brings great convenience for installation. Speaker body surface adopts fiberglass coating process, in addition to bear certain intensity hard collision, it has good water resistance feature.
It’s mainly used in large gymnasium, large theme park, large-scale cultural plaza and other occasions.
|
Model |
TS-3 |
|
Impedance |
8Ω |
|
Frequency |
130Hz～18KHz |
|
Power |
300W |
|
Sensitivity |
104dB |
|
Angle of Coverage |
(H) 50°(V) 50° |
|
High pitch |
ф44 Titanium diaphragm tweeter x 2 |
|
Bass |
12 inch bass x 1 |
|
Cabinet surface |
Black paint |
|
Connection socket |
Two 4-pin socket SPEAKON 1+ 1- |
|
Dimensions (L x W x H) |
700 x 550 x 690mm |
|
Weight |
43Kg |
